DIY Interactive Environments - Lab Automations

DIY Interactive Environments - Lab Automations

Odysseas Economides |

This project was designed as a part of the introductory 2 day Interactive Environments Workshop (OCT21) funded by CYENS - Thinker Maker Space.





LAB AUTOMATIONS



The scene is set in a lab, where several automations re needed in orders to ease the work of the people and make the work environment safer!



PARTS LIST:



PART 1 - GAS LEAK

The lab uses compressed butane gas in order to light up a fire and keep the chemical compounds destroy-chamber warm. It is mandatory for the safety of the work environment, that no butane gas leak will happen!

Arduino commands used:



Example sketch:

void setup() {

  pinMode(2,OUTPUT);

}



void loop() {

  Serial.println(digitalRead(2));

}



Challenge #1:

Write a sketch to sense when there is a gas leak in the lab and sound an alarm in combination with a blinking red LED to warn the personnel!





PART 2 - HEATER STATUS

The chamber has to be warm continuously in order to achieve the high temperatures required to be able to destroy some chemical compounds in the lab. To monitor the uptime of the flame, that is used to warm the chamber, a fire sensor is being used.

Arduino commands used:



Example sketch:

void setup() {

  pinMode(3,OUTPUT);

}



void loop() {

  Serial.println(digitalRead(3));

}



Challenge #2:

Write a sketch to sense when the fire chamber malfunctions and does not work properly, so that you can issue a warning light and sound for the tech personnel to check up and fix the chamber immediately.





PART 3 - COMPOUND DETECTION

The lab uses several chemical compounds that are stored in small, secure cubes. In order to distinguish which compound is stored inside, an rfid tag is placed outside the cube.

Arduino commands used:



Example sketch:

#include <SPI.h>

#include <RFID.h>



RFID rfid(10, 9);

String rfidCard;



void setup() {

  SPI.begin();

  rfid.init();

}



void loop() {

  if (rfid.isCard()) {

    if (rfid.readCardSerial()) {

      rfidCard = String(rfid.serNum[0]) + " " + String(rfid.serNum[1]) + " " + String(rfid.serNum[2]) + " " + String(rfid.serNum[3]);

      Serial.println(rfidCard);

      if (rfidCard == "136 4 189 85"){

        Serial.println("Plutonium");

      }

    }

    rfid.halt();

  }

}



Challenge #3:

Write a sketch to scan the rfid tags of the compounds and output its name in the serial monitor. Use the RGB LED to indicate the category of the compound, and make a different tune using the buzzer for each category.

Category 1:

  • Plutonium
  • Uranium

 Category 2:

  • TNT
  • Nitroglycerine

Category 3:

  • Mercury
  • Hydrocyanic
