DC Motor Driver L298N

€2,99
Tax included Shipping calculated at checkout.

Delivery and Shipping

Domestic shipping is handled by Akis Express in one working day for pickup points and 2-3 working days for door to door delivery. For international shipping there is option for a Post Office or a FedEx Express.

DC Motor Drive Module PWM Speed Dual H Bridge Stepper Motor L298N

This module allows for dual H-bridge motor drive, enabling control of two DC motors or a four-wire two-phase stepper motor. It can be supplied with a voltage range of 2V-10V and accepts a signal input voltage between 1.8-7V. Its single-channel operating current reaches 1.5A, with a peak current of up to 2.5A and a low standby current of less than 0.1uA. Additionally, it includes a built-in anti-co-state conduction circuit to prevent motor malfunctioning when the input is vacant. It also features a built-in thermal protection circuit with hysteresis (TSD) to prevent motor stall. With a compact size of 24.7 * 21 * 5mm (LWH) and a 2 mm mounting hole diameter, it is perfect for assembly and automotive use.

Please note that the INx pin must be connected to a microcontroller IO or other signal source.

Key Features:

This module features a professional motor drive chip, utilizing low-resistance MOS switches for minimal heat generation without the need for a heat sink. It boasts a compact design and high power output, making it a perfect replacement for the L298N, which is known for its low efficiency, high heat generation, and tendency to burn. With dual 1.5A * 2 (peak current of 2.5A) output and built-in thermal protection, the module can withstand motor stalls without the risk of damage, and will automatically restore temperature. It is also compact, lightweight, and has 0 standby current, making it the ideal choice for your car.
