This project was designed as a part of the introductory 2 day Interactive Environments Workshop (OCT21) funded by CYENS - Thinker Maker Space.
ROOM 2045
The scene is set in a future house room in 2045! It's not about the tech level that the scene is set in the future, there are a lot of similar solutions and products already available in the market, it's more about getting used to them and having them around in our daily life. We will build a room light that switches itself on when needed, convert a whole wall to a fan switch and set up an interactive art element for the room.
PARTS LIST:
- The brain - Arduino UNO
- Light intensity sensor - Photoresistor
- A headlight, a 5050 neopixel a just a LED to simulate the room’s light
- A fan or just a motor
- Shock & Knock Sensor
- Motion sensor
- Wires - Dupont Wires Kit
PART 1 - KNOCK IT
Are you walking through the room just to switch on the fan? Why not just convert the whole wall into a switch? We could do so by attaching the correct sensor on a wall! In order to simulate the idea we will use a shock & knock sensor.
Arduino commands used:
Example sketch:
void setup() {
pinMode(2,OUTPUT);
}
void loop() {
Serial.println(digitalRead(2));
}
Challenge #1:
Write a sketch to sense when there is a knock on the wall to turn on the fan for five seconds.
TIP - The fan is very simple to use, it just needs some power, use digitalWrite() to achieve it!
PART 2 - NO SWITCHES
When walking into a dark room, wouldn't it be almost the perfect solution to have the room light to automatically turn on? Well using a motion sensor, a light intensity sensor and a headlight we can build it!
Arduino commands used:
Example sketch:
void setup() {
pinMode(3,OUTPUT);
pinMode(4,INPUT);
}
void loop() {
if (digitalRead(4) == HIGH){
analogWrite(3,5);
delay (5000);
} else {
digitalWrite(3,LOW);
}
}
Challenge #2:
Write a sketch to sense when it's dark and a person comes inside the room to light up the LED.
TIP - If the LED is very bright use analogWrite() to control the intensity.
PART 3 - INTERACTIVE ART
What about having interactive art elements in our rooms in the future? We will create a colorful led panel that will change behaviour as soon as an object comes close. The ultrasonic distance sensor and the LED panel require a library to be installed in order to use it with ease, you can install the “Bifrost Library for HC-SR04” and Adafruit_NeoPixel from Sketch -> Include Library -> Manage Libraries
Arduino commands used:
This module uses only library commands, no native Arduino commands are needed.
Example sketch - ultrasonic sensor:
#include <hcsr04.h>
HCSR04 hcsr04(6, 5, 20, 4000);
void setup(){
Serial.begin(9600);
}
void loop() {
Serial.println(hcsr04.distanceInMillimeters());
delay(250);
}
Example sketch - led panel:
#include <Adafruit_NeoPixel.h>
Adafruit_NeoPixel pixels(16,4,NEO_GRB+NEO_KHZ800);
void setup() {
pixels.begin();
}
void loop() {
pixels.setPixelColor(0,200,0,0); //setPixelColor(PIXEL ID,R,G,B), where RGB values from 0-255
pixels.show();
delay(10);
}
Challenge #3:
Write a sketch to sense when an object is close and make the LED wall change colors as soon as the object gets closer.
